Hydraulic Parts

  • hose tube air quick coupler pneumatic quick connect coupling
  • Light Heavy Hydraulic Hose Clamp

    Light Heavy Hydraulic Hose Clamp

    This type of products is applicable for fixed pipes having oil , water and gas as media of meachanical hydraulic system in fixed like metallurgy ,petroleum ,chemical industry  , automobile,shipping  and electricity ,light series is applicable for fixing  Mp  and LP pipe  .

    Measurement system: Metric
    Material: Plastic
    Product name: Hose Clamp
    Type: Hardware Tools
    Color: Green
    Surface treatment: Galvenized
    Function: Fixed Pipe
    Thickness: Heavy Duty 8mm/Light Duty 3mm
    1. Structure
    Hexagon head bolt/hexagon socket bolt+cover plate+clamp body+welded base plate/rail nuts
    2. Material
     Clamp body: plastic PP-polypropylene /PA-polyamide /AL-aluminium
     cover plate:  carbon steel  (Zn-galvanised) or  stainless steel (SS 304/316)
     Bolt: carbon steel (Zn-galvanised) or stainless steel (SS 304/316)
    3. Temperature
     PP: -30°c up to + 90°c  green
     PA: -40°c up to + 120°c dark
     AL: -80°cup to 300°c grey









  • Test Point Test Coupling Threaded Female Fitting

    Test Point Test Coupling Threaded Female Fitting

    Applications:
    Pressure control
    Lubrification
    Airbleeding
    Oil sampling
    Materials:
    Galvanised carbon steel
    (Stainless steel AISI 316 is available on request)

  • Test Hoses For Micro Hydraulic And Hydraulic Systems

    Test Hoses For Micro Hydraulic And Hydraulic Systems

    Test pressure hose is applied in micro hydraulic system and testing pressure in hydraulic system.It’s specification includesjight weight.wear resistance,strong in pact res istamce, good flexibility.friendly use.and so on.

    Fluid service: mineral oil, water-glycol, alcohol, gasoline, water-oil emulsions, gas, etc.
